CFW Conveyor Belt
Our Production Range:
Belt width:400mm－3000mm
CFW Conveyor Belt
Features:low elongation, excellent impact resistance, excellent anti-tearing performance, low rolling resistance, high adhesive strength.
CFW Fabric Technical data
| Fabric Type
|
Breaking strength | Elongation at break | weight | thickness | width | Peel strength | |
| N/mm | % | g/m2 | mm | mm | N/mm | ||
| CFW200
|
warp | >240 | >15 | 650
|
0.85
|
800~1600
|
≥8
|
| weft | >80 | ≤45 | |||||
| CFW250
|
warp | >330 | >15 | 810
|
1.1
|
≥8
|
|
| weft | >90 | ≤45 | |||||
| CFW300
|
warp | >350 | >15 | 890
|
1.25
|
≥8
|
|
| weft | >100 | ≤45 | |||||
| CFW350
|
warp | >400 | >15 | 1050
|
1.30
|
≥8
|
|
| weft | >105 | ≤45 | |||||
| CFW400
|
warp | >460 | >15 | 1080
|
1.40
|
≥8
|
|
| weft | >110 | ≤45 | |||||
| CFW500
|
warp | >570 | >15 | 1350 | 1.55 | ≥8 | |
| weft | >120 | ≤45 | |||||
