Chemical Resistant Conveyor Belt
Our Production Range:
Belt width:400mm－3000mm
Chemical resistant conveyor belt
Product characteristics:
Because the belt core selects cotton-duck, nylon-duck or EP-duck, the belt has good elasticity, excellent trough ability, and low elongation. The rubber cover, which is made from chemical resistant materials, has fine anti-chemical corrosiveness and good physical properties.
Uses:
It is suitable for conveying materials with chemical corrosiveness in chemical factory ,chemical fertilizer factory, paper mill ,mining industry and etc.
Technical indexes:
| Items | Tensile strength MPa |
Elongation at break % |
Abrasion mm3 |
Hardness shore A° |
Ozone deterioration | ||
| cover
|
physical property
|
before aging | >=14.0 | >=400 | <=250 | 55-70 | no cracks |
| after aging | >=12.0 | >=340 | – | 60-75 | – | ||
| class | soak liquid | Density | soak conditions oC x96h |
change rate before and after aging | |||
| swelling rate | change rate of tensile strength | ||||||
| A1 | HCL | 18% | 50oC x96h | <+10% | <-10% | ||
| A2 | H2SO4 | 50% | 50oC x96h | <+10% | <-10% | ||
| A3 | NaOH | 48% | 50oC x96h | <+10% | <-10% | ||
